C10TX New Dual-probes Multipurpose Ultrasound Convex +linear+ Cardiac Probe

Newest C10TX Wireless bluetooth ultrasound scanner with dual probe, multipurpose handheld convex+linear+cardiac Ultrasound probe can diagnose whole body parts. C10TX can be used by wired or wireless connection to mobile phones/ipad/PC. It is IP68 waterproof, you can scan whole body part anytime anywhere.

bluetooth ultrasound
pocket ultrasound machine
pocket ultrasound
portable handheld ultrasound scanner

Specification of C10TX Dual-probes Multipurpose Ultrasound convex+linear probe

Product specs:

ProbeWireless dual head convex+linear probe
ElementsDual 128
Frequency3.5/5.0mhz, 7.5/10mhz,2.5/5.0mhz
Depth90-305mm, 20-100mm, 90-160mm
Preset 16+Abdomen, GYN, OB, Cardiac, Urology, Kidney, Lung, User1, User2
Thyroid, Small parts, pediatrics, Vascular, Carotid, Breast, Msk, Nerve, User1, User2
HostAndroid/IOS/Windows Tablet, Smart phone, PC
ConnectionWiFi&USB
Software Adjustable ParametersGN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down.
MeasurementB: Length, Area/Circumference, Angle, Trace, Distance GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL)
B+M: Heart rate, Time, Distance, LVID(LVIDd, LVIDs, EF, SV)
B+PW: Velocity, Heart rate(2), S/D, Depth.
Automatic Vessel Flow Measure:PS, ED, TAMAX, TAMEAN, PI, RI, S/D, DIAM, FL
Playback Frames100, 200, 500, 1000 optional
Display modeB, B+B, B/M, Color, PW, PDI, B+Color+PW
Image Gray Scale256 level
WiFi TypeBuilt-in WiFi, 802.11g/20MHz/5G/450Mbps
Channel64
Frame24s/f
Gain40-110Db
LanguageEnglish, Chinese,Russian, German, Italian, Frence, Ukrainian, Spanish, Portuguese
Power* by built-in 2 Lithium batteries
Battery ReplaceableYes (by engineer)
Battery Last* 4hours (Working time), 72 hours(Stand by time)
ChargerUSB Charger, wireless charger
Anti skid Design* 4 sides of probe
Waterproof grade* IP68
Built-in cooling coating* Yes


Features of C10TX Dual-probes Multipurpose Ultrasound convex+linear probe

Features of C10TX Dual-probes Multipurpose Ultrasound convex+linear probe
  • 128 element double head convex + linear + cardiac preset 3 in 1 probe

    Check abdominal organs, heart, muscles and nerves, etc.

  • Only 186g, smaller than iphone, easy to carry.

    Konted Ultrasound adopts lightweight design and is easy to carry every day.

  • B, B+B, B/M, Color, PW, PDI, B+Color+PW mode

    Multiple ultrasound mode adjustments, equipped with color ultrasound function, convenient for doctors to treat.

  • WiFi&USB, 2 connection methods, support working while charging

    Wireless charging and wired charging take the same time.

Dual head ultrasound scanner C10TX

Dual head ultrasound scanner C10TX
  • Diagnose myocardial ischemia, myocardial infarction, heart failure, arrhythmia, etc.

    Ultrasound equipment for cardiovascular physicians.

  • The linear array head on the lower side can determine the lesions of the nervous system.

    Common neurological diseases, including disorders of consciousness, can cause drowsiness, lethargy, coma, delirium, confusion, etc.

  • Assess the structure and function of the heart

    Check common heart diseases, hypertension, arrhythmia, heart failure, etc.

  • Observe the size and shape of the heart chambers, myocardial movement, and valve morphology

    Look for infections in the ventricles or valves. Valvular disease can also affect the function of the ventricles.

Dual-probes Multipurpose Ultrasound Video Display

Abdominal Ultrasound Transducer Iliac Artery B
Abdominal Ultrasound Transducer Iliac Artery B
