OB&GYN wireless ultrasound

OB&GYN wireless ultrasound

We have two ultrasonic probes with special shapes,which are C10QT and C10RC.They are all ultrasound probes designed for obstetrics and gynecology.They generate internal images of a woman's bladder, uterus, fallopian tubes, cervix and ovaries and display them on a computer screen for doctors and patients to view.Abnormal uterine bleeding, cysts, tumors, fibroids, and pelvic pain are all conditions that can be diagnosed and evaluated with pelvic ultrasound imaging.Konted is a multi-purpose ultrasound probe specially designed for obstetrics and gynecology. If you are interested, please contact us.


Difference Between KONTED Types of OB&GYN wireless ultrasound



As one of the most professional handheld ultrasound companies in China, Konted provide high-quality handheld wireless ultrasound with good services.


Model    C10QTC10RC
Probe typeConvex probe + TVS probeConvex probe + TVS probe +cardiac
connectionWiFiWiFi&USB
Battery ChargingWireless
Wireless&Type-C cable
Elements192128
Dimensions158x70x30mm114*53*30mm
Weight212g165g
RadiusR60 (convex)R45 (convex)
Scan Freq

Convex:3.5-5Mhz


TVS:6.5-8Mhz

Convex:3.2-5Mhz

Cardiac:2.5-5Mhz

TVS:6.5-8Mhz

Scan Depth

Convex:90-305mm


TVS:30-120mm

Convex:90-305mm

Cardiac:90-160mm

TVS:30-120mm

Frame rate24s/f18~24 F/S
Batteryby built-in 4200mAh batteryBuilt-in 2 High capacity Lition batteries 2600 mAh
WIFI Type
802.11n/20MHz/2.4G/5G802.11n/20MHz/2.4G/5G
Cooling coatingNoYes
Anti-skid design/Yes
Waterproof
IPX7
IP68
Model

B.B+B. B+M.B+Color.B+PW.PDI

B.B+B. B+M.B+Color.B+PW.

B+Color+PW.PDI
