C10UE is a product we developed for the ophthalmic ultrasound market, which can image and measure different parts of the eye. Helps doctors see the inner structure of the eye through dense cataracts or bleeding inside the eye. Thus, we can find treatment options for cataracts, glaucoma, lens opacity and other diseases for different groups of people.
Product specs:
| Probe | Electronic array probe |
| Elements | 128 |
| Frequency | 8-11Mhz |
| Depth | 30-70mm |
| Host | Tablet, Smart phone, PC |
| Connection | 802.11.n / 20Mhz/ 5G WIFI(AP) |
| Software Adjustable Parameters | GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down. |
| Measurement | B: Length, Area/ Circumference, Angle, Trace, Distance |
| B+M: Heart rate, Time, Distance | |
| B+PW: Velocity, Heart rate(2), S/D, Depth | |
| Playback Frames | 100, 200, 500, 1000 optional |
| Display Mode | B, B/M, color, PW, PDI |
| Image Gray Scale | 256 level |
| WiFi Type | Built-in WiFi, 802.11g/20MHz/5G/450Mbps |
| Channel | 64 |
| Frame | 24s/f |
| Gain | 40-110Db |
| Power | by built-in 2800mAh battery |
| Battery Replaceable | Yes |
| Battery Last | 3 hours(working time), More than 5 hours(stand by time) |
| Charger | wireless charger |
| Language | Chinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil) |
Check eye lesions, eye muscles, etc.
Konted Ultrasound adopts lightweight design and is easy to carry every day.
Multiple ultrasound mode adjustments, equipped with color ultrasound function, convenient for doctors to treat.
Wireless charging and wired charging take the same time.
Assists in the diagnosis of posterior scleral rupture, determines the location and nature of foreign bodies in the eyeball, and evaluates the nature of intraocular tumors.
Eye diseases like cataracts, glaucoma, retinal detachment, and macular degeneration.
Enables early detection and diagnosis of retinal vasculopathy.
Helps in the calculation of intraocular lens power during cataract surgery and the auxiliary diagnosis of congenital microphthalmia, congenital glaucoma, etc.
