Gen4Pro 256-element wireless ultrasound probe C10H was launched in 2018. Scanning frequency 7.5-10Mhz, scanning depth 20-100mm. Application:hip bone,breast,thyroid,superficial etc. It is more convenient than portable laptop ultrasound.
Probe | Wireless super width linear probe (L80) |
Elements | 256 |
Frequency | 7.5-10Mhz |
Depth | 40-100mm |
| Presets | Thyroid, Small parts, Pediatrics, Vascular, Carotid, Breast, MSK, Nerve |
Host | IOS/Android/Windows, Tablet, Smart phone, PC |
Connection | WiFi (USB optional) |
Software Adjustable Parameters | GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote |
Measurement | B: Length, Area, Circumference, Angle, Trace, Distance B+M: Heart rate, Time, Distance |
| B+PW:Velocity,Heart rate(2), S/D, Depth | |
Playback Frames | 100, 200, 500, 1000 optional |
Display Mode | B, 2B, B+M, Color, PW, PDI |
WiFi Type | Built-in WiFi, 802.11g/20MHz/5G/450Mbps |
Channel | 64 |
Frame | 24s/f |
Gain | 40-110Db |
Language | Chinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil) |
Power | by built-in 4200mAh battery |
Battery Replaceable | Yes |
Battery last | 3hours (Working time), 12hours (Stand by time) |
Charger | Wireless charger |
Connect Android/IOS/Windows Smartphone, tablet, PC.
Small size, light weight 200g~240g, wireless use.
128 elements, 4-level image optimization technology, White&Black WIFI ultrasound.
