Beijing Konted Medical Technology Co.,Ltd.

C10CX Color Superfical Ultrasound HD Linear Probe

Gen4 Pro C10CX ultrasonic probe launched in 2018, the probe body has 3 activation buttons, scanning frequency 7.5-10mhz, 192 elements color Doppler wireless convex probe, can provide rapid high-definition ultrasound images for anesthesiologists, physiotherapists, etc. Konted as one of the most professional handheld ultrasound manufacturers, we assure to provide high-quality wifi wireless portable ultrasound scanner.

linear transducer ultrasound
linear phased array transducer
ultrasound linear transducer
ultrasound probe linear
cx
cx1

Specification of C10CX Color Superfical Ultrasound HD Linear Probe

Product specs:

ProbeWireless linear probe
Elements192
Frequency7.5-10Mhz
Depth

20-80mm

PresetsThyroid, Small parts, Pediatrics, Vascular, Carotid, Breast, MSK, Nerve
HostIOS/Android/Windows, Tablet, Smart phone, PC
ConnectionWiFi
Software Adjustable ParametersGN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote
MeasurementB: Length, Area, Circumference, Angle, Trace, Distance
B+M: Heart rate, Time, Distance
B+PW:Velocity,Heart rate(2), S/D, Depth
Playback Frames100, 200, 500, 1000 optional
Display ModeB, B/M, Color, PW, PDI, B+B
WiFi TypeBuilt-in WiFi, 802.11g/20MHz/5G/450Mbps
Channel64
Frame24s/f
Gain40-110Db
LanguageChinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil)
Powerby built-in 4200mAh battery
Battery ReplaceableYes
Battery Last3hours (Working time), 12hours (Stand by time)
ChargerWireless charger, USB cable



Features of C10CX Color Superfical Ultrasound HD Super-Width Linear Probe

Features of C10CX Color Superfical Ultrasound HD Super-Width Linear Probe
  • Multi-system platform

    Connect Android/IOS/Windows Smartphone, tablet, PC.

  • Easy to operate and carry

    Small size, light weight 200g~240g, wireless use.

  • High-definition image

    128 elements, 4-level image optimization technology, White&Black WIFI ultrasound.

Color Color Superfical Ultrasound Video Display

Curved Linear Array Transducer B Gallbladder
Curved Linear Array Transducer B Gallbladder
Curved Linear Probe Median Nerve
Curved Linear Probe Median Nerve
Abdominal Ultrasound Transducer Iliac Artery B
Abdominal Ultrasound Transducer Iliac Artery B
Curved Linear Ultrasound Probe Finger Flexor Tendon
Curved Linear Ultrasound Probe Finger Flexor Tendon
Linear Array Probe Brachial Plexus
Linear Array Probe Brachial Plexus
Linear Array Probe Ultrasound Axillary Artery C
Linear Array Probe Ultrasound Axillary Artery C
